ITQ Electric Actuator
Model: ITQ0020~ITQ9000
Category: Automatic/Industrial Machines & Equipments / Automated Machinery & Equipments / Automatic Control Systems
Characteristics
1.Compact and robust construction, light weight providing high output
torque(Max 9000Nm).
2.Wide range of torque variation (From min 100Nm to max 9000Nm).
3.Hard anodized aluminum housing inside and outside with external
powder coated against severe industrial environment.
4.Enclosure using radial seals & O-rings that provide protection to
waterproof IP67(Nema 4 & 6) and optional watertight IP68.
5.Mounting base according to ISO5211 standard.
6.Removable drive bushing for easy machining and mounting.
7.Self-locking provided by double worm gearing (no brake required).
8.Auto-declutching manual override handwheel with padlockable
auto / manual switchable lever.
9.Reliable Mechanical Torque sensing system providing safe
operation in overload condition.
10.Large size window and indicator provides better position indication
from a distance.
11.Various Local position control options providing easy
commissioning and operation in field.
12.Digitalized control component.
