Umbrella-type Tool Magazine /ATC
Model: DVS
Category: Machine Tools / Machining Centers / Vertical Machining Centers, Double-Column-Type
Characteristics
◆ By I/O communication, it can be used with any brand of controller and system.
◆ Fully enclosed tank type transmission system prevents dust, reduces failure rate, saves maintenance time.
◆End tracking encoder prevents positioning not precise by transmission system abrasion after long term usage.
Specifications
| Tool Specification | E32 |
| Tool loading capacity | 13 |
| Tool disk indexing time (opposing tool) | 1.2sec |
| Tool disk indexing time (adjacent tool) | 0.5 sec. |
| Max tool diameter (full tool) | Φ60mm |
| Max tool weight | 3kg |
| Max tool length | 150mm |
| Driving voltage | AC 220V |
| Magazine weight | 41.5KG |
