Indexing Drives

Enlarge

Indexing Drives

Modeeel: Flange Model / F Series

Industry: Automatic/Industrial Machines & Equipments / Automated Machinery & Equipments / Automatic Control Systems

Supplier; Siang Sheng Precision Machinery CO.,LTD.

Booth No: J310

Characteristics

1. F series endures heavy loading. It bears greater radial or axle directive output. Suitable for rotatary turntable transimissive works with greater loading.

2. The output shaft in flange design, rotating and processing turntables
　can be positioned directly on flanges. The face of the fixture is wide and grinded to ensure the flatness of positioned platform.

3. This model is widely used in automotive transmissive turntables,
　various platform-like processing machines and other industrial machineries applicable.

Specifications

CAM box spec(axle distance/mm)：45,60,70,80,110,140,180

DS(indexing type) Indexing count：2,3,4,5,6,8,10,12,15,16,20,24,30,32,36,40,48

ES(Sway type) Sway angle(deg)：5,10,15,30,45,60,90

RS(Precision gear reducer) Reducing rate： 3,4,5,6,8,10,12

Input shaft transmission speed(rpm)：0～700
