Indexing Drives

Modeeel: Hollow Flange Model / H Series

Industry: Automatic/Industrial Machines & Equipments / Automated Machinery & Equipments / Automatic Control Systems

Supplier; Siang Sheng Precision Machinery CO.,LTD.

Booth No: J310

Characteristics

1. The dimension and function of this model is identical to the Flange
　models, except the output shaft of Hollow Flange model is hollow.

2. The hollow design of the shafts lets through pneumatic, hydraulic, and electrical pipes and wires through, saving the space and preserving orderliness. Automation utilities and material in-feed system can also be placed in hollow space of the shafts.

Specifications

CAM box Spec(axle distance/mm)：45,60,70,80,110,140,180

DS(indexing type) Indexing count：2,3,4,5,6,8,10,12,15,16,20,24,30,32,36,40,48

ES(sway type) Sway angle(deg)：5,10,15,30,45,60,90

RS(Precision gear reducer) Reducing Rate：3,4,5,6,8,10,12

Input shaft transmission speed(rpm)：0～700
