Oscillating Handler

Enlarge

Oscillating Handler

Modeeel: Up-Down Sway Model / FN Series

Industry: Automatic/Industrial Machines & Equipments / Automated Machinery & Equipments / Automatic Control Systems

Supplier; Siang Sheng Precision Machinery CO.,LTD.

Booth No: J310

Characteristics

1. Up-down sway model is the mechanism assembled by back-and-forth excises and intermittent motions or left-right swings of output shaft.

2. Output shaft partner with turntable and swinging arm. Suitable for high precision and high speed machines requiring picking up and pulling out motions.

3. Special vertical motion mechanism design is shock-free during shaft’s back-and-forth exercises.

Specifications

Indexing count(FN Series)
Axle distance 60：2,3,4,6,8
Axle distance 100：2,3,4,6,8,10,12

Sway Angle (Unit : deg)
Axle distance 60：0～180
Axle distance 100：0～90

Ascending Schedule (Unit : mm)
Axle distance 60：max.25
Axle distance 100：max.30

Input shaft transmission speed (Unit : rpm)
Axle distance 60：max.200
Axle distance 100：max.120
