Oscillating Handler

Enlarge

Oscillating Handler

Modeeel: Up-Down Flange Model / MF Series

Industry: Automatic/Industrial Machines & Equipments / Automated Machinery & Equipments / Automatic Control Systems

Supplier; Siang Sheng Precision Machinery CO.,LTD.

Booth No: J310

Characteristics

1. The properties of the series are the same as the FN model. Output in
　flange design. Pair with larger diameter turntable.

2. Center output shaft is also available in hollow shaft design. Proper fit
　with pneumatic and gas pressured revolving connector, makes it easy on controlling picking up motions.

3. This series is also available in “detached ascending style”. Shaft
　exercises up-down motion independently while flange does intermittent indexing.

Specifications

Indexing count(MF Series)
shaft space 70：2～32
shaft space 80：2～32

Sway Angle (Unit : deg)
shaft space 70：0～90
shaft space 80：0～90

Ascending Schedule (Unit : mm)
shaft space：max.30
shaft space 80：max.40

Input shaft transmission speed (Unit : rpm)
shaft space 70：max.100
shaft space 80：max.100
