XCS7013-C-T-P4S-UL Spindle bearing, XCS7013-C-T-P4S-UL bearing
Release date：2013/10/21
Description: Machine tool main spindle bearing, we had exported the bearing XCB7013-C-T-P4S-UL to Brazil country.
Type : XCS7013-C-T-P4S-UL bearing Machine tool main spindle bearing
Dimension: 65x100x18 mm/Metic
ID(inner diameter)/Bore:65mm
OD(outer diameter):100 mm
Width/Height/thickness: 18 mm
Basic Dimensions(mm)
Bearing Designations
Precision Rating
basic load rating(KN)
Limiting Speed
(r/min)
Weight
(KGS)
d
D
B
Cr
Cor
Grease
oil
65
100
18
XCS7013-C-T-P4S-UL
P4
61
24.5
22000
36000
0.36
FAG XCS7013-C-T-P4S-UL bearing is super precision ball bearing for main spindle, it's particularly suitable for supporting high axial forces, offering even more precise machining results and higher cutting performance for the application. If you have just landed here, this product XCS7013-C-T-P4S-UL bearing, You can call us or send enquiry, we would give you the prices, packing, and more detailed information on the XCS7013-C-T-P4S-UL bearing .
We cooperate with DHL,TNT,FEDEX,UPS,EMS, and shipping agency etc.They guarantee to meet your needs in terms of time and money, , YES, we ship worldwide. We had a lot of bearing in our warehouse, if we have no stock, the manufacture time:5-10 days.
XCS7013-C-T-P4S-UL the Bearing inner ring and outer ring forging material:GCr15SiMn ,GCr15, Chrome steel.
The Inner ring and outer ring hardness: 58-62HRC
The manufacture process including: Lathe process, Heat treatment process, Grinding process, Assembly process and final inspect process and on on.
The package: standard export wooden case or FAG standard carton boxes.
