CNC Angle Drilling and Marking Line
Model: TBL2532
Category: Automatic/Industrial Machines & Equipments / Automated Machinery & Equipments / Hydraulic Automatic Machines
Characteristics
Feature Products
1.cnc angle line for punching,shearing and marking
3 in tower fabrication
4 high speed cnc angle
Product Description
CNC Angle Drilling and Marking Line
Applicable Industry:
The machine is the special equipment used for angle steel drilling & marking mainly in the field of angle steel tower industry.
Specifications
CNC Angle Drilling and Marking Line
Applicable Industry:
The machine is the special equipment used for angle steel drilling & marking mainly in the field of angle steel tower industry.
Specifications:
Model TBL2532
Angle size(mm) 140x40x0~250x50x2
Marking force(kN) 1030
Max. Length of blank(m) 14
Max. Length of finished(m) 14
No. Of drill an each side(piece) 3
No. Of character group(piece) 1
No. Of character in each character size(piece) 15
Character side(mm) 14x0x9
Range of back mark (mm) 50-220 (stepless)
CNC axes(piece) 3
Spindle rotation speed(r/min) 180-560, Transducer stepless adjustment
Feeding speed of angle(m/min) 30
Diameter of drilling(mm) 17.5~40
Stroke of Spindle(mm) 180
Processing precision Accordance with GB2694-81
Programming mode Input by keyboard, RS232 interface, floppy disk and USB interface
Overall dimensions (m) 32x. 9x. 2
Gross weight of machine(kg) Approx. 16800
Total power(kW) 35
We welcome customers to visit our factory at any time. No wait, please order now!
