Specifications



Punching: Electric Punch ( by Foot Pedal)

Binding: Manual

Capacity: Max. 20 Sheets PPC Paper ( 70 g / m2 )

Capacity: 3/16"(5.5mm) ~ 2"(50mm)

Available Length: Max. 14"

Productivity: 30~450 sheets

Binding Length: Max. 14"

Anti-Jam Function: Reverse Switch for paper jam clearance

Safety Device: Automatic Power failure for protection

Depth margin control: 4 section at 2mm, 3mm, 4mm and 5mm

Disengaging Dies: 24 dies

Punching Speed: 1.5 seconds per punch cycle

Hole Punch: (PITCH 9/16"－24 dies) / Rectangular 7.96mm * 3.14mm

Machine Dimension: 410(L)mm*480(W)mm*400(H)mm

Machine Weight: 27 kgs

Transmittal Method: Electric Magnetic Brake Motor

Normal rated power: 90W

Voltage: AC115V，50 / 60 HZ
AC230V，50 HZ
