Wide Fine Grinder Used in Cassava Processing Plant
Model: SFSP668
Category: Automatic/Industrial Machines & Equipments / Industrial Machines / Agricultural Machinery
Characteristics
Features
1. It is used for grinding raw materials of large and medium livestock and aqua feed mills. It can also be used for grass and pharmacy fine grinding. The granular raw materials, such as corn, sorghum, wheat, beans, etc can be ground;
2. It is derived from the tear circle type hammer mill and efficiency can be improved by 45%-90% compared to universal hammer mill;
3. It can produce qualified aqua feed under full load with ¢0.8, ¢1 screen and reduce jam significantly. Both coarse and fine grinding can be completed without changing screens;
4. The right aspiration can make materials go through screen quickly, reduce temperature of grinding chamber and increase output effectively.
Specifications
Main Technical ParametersG
Parameters Model |
Dia. Of Rotor (mm) |
Width Of Grinding Chamber (mm) |
Speed Of Rotor (r/min) |
Speed Of Beater (m/s) |
No. Of Beater (pc) |
Power (kw) |
Aspiration (m³/min) |
Output(t/h) |
|
Coarse |
Fine |
||||||||
SFSP668- |
660 |
380 |
2970 |
94 |
56 |
22/30 |
30 |
34 |
5-6 |
SFSP668- |
660 |
450 |
2970 |
94 |
64 |
45/55 |
40 |
45 |
7-12 |
SFSP668- |
660 |
600 |
2970 |
94 |
88 |
55/75 |
48 |
53 |
10-15 |
SFSP668- |
660 |
750 |
2970 |
94 |
112 |
90/110 |
60 |
66 |
15-20 |
Re: The above indexes are those when meeting the following conditions: raw material: corn, moisture content not higher than 14%, density not lower than 0.72t/m3, screen: hole diameter F3mm, hole-opening rate not less than 33%
