Specifications

Helical-Bevel Geared Motors K series gearbox

@Professional Manufacturer of K series 90 degree helical gearbox with ac electric motor designation

Example: GK(AF)77-52.07-M2

G:Guomao Reducer Group

K: K series helical bevel gearbox

(AF): None-shaft output, F-flange output with solid shaft, A-Output hollow shaft type. H-Hollow shaft output with shrink disk AT- Torque-arm mounted (S17…R77)- Combined types

77:Gearbox model number

52.07: Gear reduction ratio

M2: Mounting way

*Application  Case

K series gear reducer is widely used in light industry, food, beer and beverage, chemical industry, escalator, automated warehousing equipment, building materials machinery, steel metallurgy, environmental protection, power plants, coal, mining, papermaking, Airports, docks), tobacco machinery and other fields.

@Professional Manufacturer of K series 90 degree helical gearbox with ac electric motor parameter

Power range: 0.12-160kW

Output speed(r/min): 0.05 - 809

Output Torque(N.M): Top to 36000N.m

@Professional Manufacturer of K series 90 degree helical gearbox with ac electric motor feature

Models:12 models ranging from K37 to K187

Large output torque,smooth startup,high efficiency

Noise Level: Low type 65-75 Db, Smooth and stable in run

Material: Carburized gears & shafts and gears HRC58-62

Transmission efficiency: the efficiency of single machine is bigger than 90%.

Equipped with spiral bevel transmission which meets 90 output requirements.

Output way:Hollow shaft with keyed connection, shrink disk, splined ,solid shaft etc.

Bearing: China standard. But SKF, FAG, NSK, TIMKEN, NTN, KOYO, C&U is a aviable if need

Mounted way: Hollow shaft,foot-mounted,flange-mounted,shaft-mounted,flange-mounted with hollow shaft,foot-mounted with hollow shaft
