PKN-76 Portable Inner Expand Type Metal Pipe Beveling Machine
Model: PKN-76
Category: Automatic/Industrial Machines & Equipments / Industrial Machines / Grinders and Crushers
Characteristics
PKN-76 Portable Inner Expand Type Metal Pipe Beveling Machine
Specifications
PKN-76 Portable Inner Expand Type Metal Pipe Beveling Machine pipeline groove machine Manufacture in China
PKN series pipe beveling machine is an inner inflation mounted card type pipe beveling machine, using single phase AC 220V power supply double insulation treatment, manual feed.
It has the advantages of small size, light weight, high power, high quality, fast speed and wide application range.
One person can work in any direction.
It is an ideal groove tool for field maintenance and production in power plants or other industries.
PRODUCT FEATURES
PKN series pipe beveling machine is an inner up mounted card type pipe beveling machine, using single phase AC 220V power supply double insulation treatment, manual feed. It has the advantages of small size, light weight, high power, high quality, fast speed and wide application range. One person can work in any direction. It is an ideal groove tool for field maintenance and production in power plants or other industries.
Product Type |
PKN-76 |
PKN-160 |
PKN-400 |
Scope of Bevelling |
Internal Dia:27mm External Dia: 76mm |
Internal Dia:56mm External Dia:160mm |
Internal Dia:111mm External Dia: 402mm |
Thickness of groove |
12 |
20 |
20 |
Distance of cutting feed |
30 |
30 |
50 |
Power Parameter |
220V/50HZ |
220V/50HZ |
220V/50HZ |
Motor Power |
1300 |
1300 |
1300 |
Motor Brand |
Metabo, Germany |
Metabo, Germany |
Metabo, Germany |
Operation Weight kg |
5 |
20 |
25 |
