Continuous Flow Seeds Dryer
Model: 5HXG-60
Category: Automatic/Industrial Machines & Equipments / Industrial Machines / Agricultural Machinery
Characteristics
1.The dryer uses the low temperature cycling;
2.Timing mode, auto mode, seeds mode,demand the customers various operating requirements;
3.Excellent burner, Online watershed instrument, PLC controller, Temperature module,make sure more accurate, reliable, design energy saving, environmental protection, and efficient;
4.Humanized design touch screen,easy operation;
5.Horizontal multi-slot drying section, thin valley floor, large drying area, high thermal efficiency, uniform heating;
6.Special temperature control prevent excessive drying grain, fissuring,and maintenance is simple, clean quickly.
Specifications
Model |
5HXG-60 |
|
Paddy processing capacity¡]kg¡^ |
1000~6000 |
|
Wheat processing capacity(kg) |
1000~6800 |
|
Soybean processing capacity(kg) |
1000~7200 |
|
Corn processing capacity(kg) |
1000~6200 |
|
Size |
Length¡]mm¡^ |
3360 |
Width¡]mm¡^ |
1785 |
|
Height¡]mm¡^ |
5680 |
|
Weight¡]kg¡^ |
1415 |
|
Blower |
Model |
GSF-600 |
Species |
Centrifugal |
|
Common Swing speed (r.p.m) |
1450 |
|
Burner |
Model |
OM-2N |
Species |
Two Fire, High pressure gun |
|
Ignition Method |
Automatic ignition, Automatic oil |
|
Combustion volume (L/h) |
3.0-12.0 |
|
Fuel |
No. 0 Diesel Oil or Kerosene |
|
Fuel tank capacity¡]L¡^ |
95 |
|
Rated voltage¡]V¡^ |
Three-phase 380 |
|
Power |
Conveying motor¡]KW¡^ |
1.1 |
Blower¡]KW¡^ |
3.7 |
|
Auger motor¡]KW¡^ |
0.75 |
|
Grain discharge motor¡]KW¡^ |
0.3 |
|
Control panel¡]KW¡^ |
0.2 |
|
Using Maximum Electricity at the same time¡]KW¡^ |
6.09 |
|
Performance Performance |
Paddy Feeding time¡]Min¡^ |
27-32 |
Wheat Feeding time¡]Min¡^ |
27-32 |
|
Soybean Feeding time(Min) |
26-31 |
|
Corn Feeding time(Min) |
27-32 |
|
Paddy Discharge time¡]Min¡^ |
21-26 |
|
Wheat Discharge time¡]Min¡^ |
19-24 |
|
Soybean Discharge time(Min) |
25-30 |
|
Corn Discharge time(Min) |
19-24 |
|
Paddy Precipitation rate(% per hour) |
0.7-1.0 |
|
Wheat Precipitation rate(% per hour) |
0.8-1.2 |
|
Soybean Precipitation rate(% per hour) |
0.4-0.5 |
|
Corn Precipitation rate(% per hour) |
0.5-0.7 |
|
Other |
Safety device |
Full volume alarm. Thermal relay, Pressure Switch, Pressure sensor, Fire Monitor, Fuse, Air temperature sensor, Grain temperature sensor, Outside temperature sensor. |
Operation mode |
Timing mode, Automatic mode, Seeds mode. |
|
Standard Equipment |
Moisture Meter Tester, Dust Machine, Ladder, Grain discharge gates |
|
Optional heat |
Stove, Steam heat exchanger, Gas burner. |
