PV Inverter
Model: FPM8C2104
Category: Automatic/Industrial Machines & Equipments / Industrial Machines / Automated Equipment for Transformers and Rectifiers
Characteristics
Item
Specification
DC Input
Maximum Input Voltage (V)*¹
600
MPPT Voltage Range (V)
40~560
Startup Voltage (V)
50
Rated Input Voltage (V)
360
Max Input Current per MPPT (A)
20
Max Short-Circuit Current per MPPT (A)
26
Number of MPPTs
2
String Count per MPPT
1
AC Output
Rated Output Power (W)
8,000
Max Output Active Power (W)
8,800
Max Output Apparent Power (VA)
8,800
Rated Output Voltage (V)
220, L/N/PE
Output Voltage Frequency (Hz)
50
Max Output Current (A)
40.0
Power Factor
~1 (Adjustable: 0.8 leading...0.8 lagging)
Total Current Waveform Distortion Rate
<3%
Specifications
|
Item |
Specification |
|
DC Input |
|
|
Maximum Input Voltage (V)*¹ |
600 |
|
MPPT Voltage Range (V) |
40~560 |
|
Startup Voltage (V) |
50 |
|
Rated Input Voltage (V) |
360 |
|
Max Input Current per MPPT (A) |
20 |
|
Max Short-Circuit Current per MPPT (A) |
26 |
|
Number of MPPTs |
2 |
|
String Count per MPPT |
1 |
|
AC Output |
|
|
Rated Output Power (W) |
8,000 |
|
Max Output Active Power (W) |
8,800 |
|
Max Output Apparent Power (VA) |
8,800 |
|
Rated Output Voltage (V) |
220, L/N/PE |
|
Output Voltage Frequency (Hz) |
50 |
|
Max Output Current (A) |
40.0 |
|
Power Factor |
~1 (Adjustable: 0.8 leading...0.8 lagging) |
|
Total Current Waveform Distortion Rate |
<3% |
