Steel plate for Boiler Pressure Vessel ASTM A37 RCI A 285 Gr. C-A 414 Gr. C / A 516 Gr. 55
Model: katalor-1
Category: Textile, Sewing, Garment Machinery & Industrial Equipments / Used Machines / Used Machines
Characteristics
A 285 Gr. C-A 414 Gr. C / A 516 Gr. 55 steel plate, ASTM A 285 Gr. C-A 414 Gr. C / A 516 Gr. 55 steel plates is a kind of material for boiler and pressure vessel steel. UNI 36087 A37 RCI steel plates is characterised by a minimum yield strength of 170-230MPa and by good weldability,so A 285 Gr. C-A 414 Gr. C / A 516 Gr. 55 steel is mainly used to for manufacturing boilers, pressure vessels and pipes transporting hot liquids.the following are ASTM A 285 Gr. C-A 414 Gr. C / A 516 Gr. 55steel plate's Chemical composition and mechanical properties
Specifications
Steel plate for Boiler Pressure Vessel ASTM A37 RCI A 285 Gr. C-A 414 Gr. C / A 516 Gr. 55
A 285 Gr. C-A 414 Gr. C / A 516 Gr. 55 steel plate, ASTM A 285 Gr. C-A 414 Gr. C / A 516 Gr. 55 steel plates is a kind of material for boiler and pressure vessel steel. UNI 36087 A37 RCI steel plates is characterised by a minimum yield strength of 170-230MPa and by good weldability,so A 285 Gr. C-A 414 Gr. C / A 516 Gr. 55 steel is mainly used to for manufacturing boilers, pressure vessels and pipes transporting hot liquids.the following are ASTM A 285 Gr. C-A 414 Gr. C / A 516 Gr. 55steel plate's Chemical composition and mechanical properties
A 285 Gr. C-A 414 Gr. C / A 516 Gr. 55 Chemical analysis -% by mass*
Grades |
C max |
Si max |
Mn. max |
P max |
S max |
N max |
AL min |
Cr max |
Cu max |
Mo max |
Ni max |
Nb max |
Ti max |
V max |
A 285 Gr. C-A 414 Gr. C / A 516 Gr. 55 |
0.16 |
0.35 |
0.60-1.20 |
0.025 |
0.015 |
0.012 |
0.02 |
0.3 |
0.03 |
0.08 |
0.3 |
0.02 |
0.03 |
0.02 |
A 285 Gr. C-A 414 Gr. C / A 516 Gr. 55 Mechanical properties
Gade |
Thickness (mm) @ |
Yield Strength MPa(min) |
Tensile Strength MPa @ |
Elongation % (min) @ |
Impact Energy (KV J) (min) |
||
-20J |
0J |
20J |
|||||
A 285 Gr. C-A 414 Gr. C / A 516 Gr. 55 @ @ @ |
≤ 16 |
235 |
360 to 480 |
24 |
27 |
34 |
40 |
16t ≤40 |
225 |
360 to 480 |
24 |
27 |
34 |
40 |
|
40t ≤60 |
215 |
360 to 480 |
24 |
27 |
34 |
40 |
|
6t ≤100 |
200 |
360 to 480 |
24 |
27 |
34 |
40 |
|
100t ≤150 |
185 |
350 to 480 |
24 |
27 |
34 |
40 |
|
150t ≤250 |
170 |
350 to 480 |
24 |
27 |
34 |
40 |
