Autoloader
Model: WSAL-300G
Category: Automatic/Industrial Machines & Equipments / Automated Machinery & Equipments / Automatic Feeding Equipment
Characteristics
●Small and light,which can be directly mounted on dryre and nolding moachine's feeding port.
●Controlied by microprocessor.
●Alarns for motor ovrload and material shortage.
●300G adopts high-speed brush motor with a small footprint and strong suction, applicable for conveying virgin materials.
●Features cable controller for quick adjustment.
●Able to be installed with bag filter(optional)
Specifications
| 型号Model | WSAL-300G | |
| 马达Motor | 形式 Type |
碳刷式 Carbon Brush |
| 规格 Specification |
1KW/1.3HP 1Ф | |
| 输送能力(kg/h) conveying Capacity |
300 | |
| 吸料扬程（m） Pump Lift |
3.5 | |
| 静风压(bar) Static Wind Pressure |
0.13 | |
| 储料桶容量(L) Storage Tank Volume |
6 | |
| 送料管内径(mm） Conveying Tube Inner Diameter |
Ф38 | |
| 配送料管 Size of Standard Hose |
Ф38mm×3.5m×1pcs | |
| 外形尺寸(cm） Dimension L×W×H |
34×34×59 | |
| 净重 (kg) Net Weight |
12 | |
