Planetary reducer
Model: BD64-L1-10-P2-F1
Category: Automatic/Industrial Machines & Equipments / Auto-Control Panel Design/Installation / Servo Systems
Characteristics
Planetary reducer - flange type (disc type) BD
Planetary reducer-flange type (disc type) BD, the characteristic output shaft end adopts rolling tapered bearing, which greatly improves the axial load capacity. Minimum precision backlash3 arc-min. With the design of the hollow output shaft, the transmission parts can be directly installed and fixed on the inner holes of the screws on the circular flange surface, saving space. The efficiency can reach 94~97% at full load, effectively increasing the torque of the servo motor and reducing the output speed. The integrated planetary gear holder and output shaft are arranged with full needle rollers in the inner hole of the planetary gear, and the frame numbers are 47, 64, 90, 110, 140, and 200mm. Provide the most suitable performance output and precise transmission, suitable for precision transmission reduction mechanism and lifting torque applications.
Specifications
Planetary reducer - flange type (disc type) BD
Planetary reducer-flange type (disc type) BD, the characteristic output shaft end adopts rolling tapered bearing, which greatly improves the axial load capacity. Minimum precision backlash3 arc-min. With the design of the hollow output shaft, the transmission parts can be directly installed and fixed on the inner holes of the screws on the circular flange surface, saving space. The efficiency can reach 94~97% at full load, effectively increasing the torque of the servo motor and reducing the output speed. The integrated planetary gear holder and output shaft are arranged with full needle rollers in the inner hole of the planetary gear, and the frame numbers are 47, 64, 90, 110, 140, and 200mm. Provide the most suitable performance output and precise transmission, suitable for precision transmission reduction mechanism and lifting torque applications.
