Pneumatic sealless plastic strapping tool P359
Model: P359
Category: Packaging, Printing, Food & Pharmacy Machinery / Packaging Machinery / Others (Package Tools)
Characteristics
The FROMM P359 delivers an impressive high tension of up to 7000N (1575 lbs). This new P359 will change the way of packaging in the ferrous and non-ferrous industries, creating massive savings. The unique high tension allows you to pull heavy duty PET strapping, with break-loads up to 17000N in its working range of 40 to 50%, thus enabling a higher level of shock absorption.
Specifications
Strapping qualities: Polyester (PET)
Stapping dimensions: widths
thicknesses
19.0 – 32.0 mm / 3/4 – 1 1/4”
0.60 – 1.53 mm / .023 – .060” Weight incl. bracket: 8.9 kg /19.6 lbs
Dimension without bracket:
L372 x W176 x H146 mm / 14.7” x 6.9” x 5.7” Average seal strength: up to 75% (dependent on strap quality)
Type of seal:
Friction weld sealing Strap tension: 2000 – 3500 N / 450 – 785 lbs (adjustable) or 4000 – 7000 N / 900 – 1570 lbs (adjustable)
Tensioning speed:
120 mm/s / 4.7 inch/s or
60 mm/s / 2.4 inch/s Max. air pressure: 6.0 bar / 87 psi
