Specifications



Electricity 220V / 380V 50/60Hz 3Phase+Ground
Power consumption 22 KW
Compressed air capacity 200 Liter/Min
High precision index Guarantee precision: ±0.05 m/m
Dimension (L x W x H) 3,380 x 2,000 x 2,100 mm
Control system OMRON PLC System
Loading / Unloading system Automatic stack lifting system
UV Lamp curing unit 3.6 KW x 3 sets
Preformance (Maxmum) 60 pcs/min
Net Weight 6,500 KG
UV Exhaust air 28m3/min(60Hz) 20m3/min(50Hz)
