Specifications

Input Requirements:PREFIX = O

Input Voltage Range:11.2VDC—14.8VDC

Input Current Range:12.0A Max @11.2VDC

Input Inrush Current：12.0Vmax@12VDC

Working Efficiency：≥85%

Output Requirements:5 group power output

 Protection Function:（For +3.3V，+12V,+5.00V and +5.00VSB power output)

Over-current Protection:When the output current get to its peak value,output shut down.

Short-circuit Protection:When output get short-circuit,output shut down.

PREFIX = V

Working Environment:

Working Temp/Humidity:15℃to 35℃/ 45%-75%

Storage Temp/Humidity:-40℃to +70℃/ 10%-90%

atm press：86Kpa—106Kpa

 Application Area:

Mini PC;IPC;AIO
