Liquid Crystal Material for PDLC RM82 125248-71-7
Model: 002
Category: Machinery Parts and Components / Machinery Parts and Components / Blowers
Characteristics
Liquid Crystal Material for PDLC RM82 125248-71-7
Nematic liquid crystal RM82 125248-71-7
1,4-BIS-[4-(6-ACRYLOYLOXYHEXYLOXY)BENZOYLOXY]-2-METHYLBENZENE
C39H44O10
HPLC: 95% MIN.
Specifications
Liquid Crystal Material for PDLC RM82 125248-71-7
| nematic liquid crystal E7 |
| liquid crystal superior to E7 | QYPDLC-7 |
| Lower Operating Temperature Tkn(C) | -10 |
| Upper Operating Temperature Tni(C) | 60 |
| Viscosity (mm2s-1,20C) | 56 |
| Birefringence(589nm,20C) | 0.227 |
| Ordinary Refractive Index (No)(589nm,20C) | 1.52 |
| Refrective index Extraordinary (Ne)(589nm,20C) | 1.747 |
| Dielectric anisotropy(1KHz,20C) | 16.3 |
| ε⊥(1KHz,20C) | 5.6 |
| Electrical properties V90(VAC),0,20(V) | 2.1 |
| Electrical properties V10(VAC),0,20(V) | 1.51 |
Established in 2007,
Qingdao QY Liquid Crystal Co., Ltd
is a leading manufacturer specializing in high-quality
nematic liquid crystals, primarily used in PDLC smart film
and high grade of LC display.
With over 18 years of nematic liquid crystals production expertise.
Featured products
-
Liquid Crystal Material for PDLC RM82 125248-71-7
-
E7 nematic liquid crystal QYPDLC-7
-
5CB nematic liquid crystal 40817-08-1
-
liquid crystals making PDLC film RM257 174063-87-7
-
Liquid Crystal PDLC applications QYPDLC-036
-
nematic liquid crystals PDLC E7 QYPDLC-421
-
Chiral Dopants S-5011 Liquid Crystal 693227-30-4
