Autoloader
Model: WSAL-300G
Category: Automatic/Industrial Machines & Equipments / Automated Machinery & Equipments / Automatic Feeding Equipment
Characteristics
Small and light,which can be directly mounted on dryre and nolding moachine's feeding port.
Controlied by microprocessor.
Alarns for motor ovrload and material shortage.
300G adopts high-speed brush motor with a small footprint and strong suction, applicable for conveying virgin materials.
Features cable controller for quick adjustment.
Able to be installed with bag filter(optional)
Specifications
号Model | WSAL-300G | |
马达Motor | Φ Type |
Ҩꦡ Carbon Brush |
规 Specification |
1KW/1.3HP 1Ф | |
输eO(kg/h) conveying Capacity |
300 | |
l扬{]m^ Pump Lift |
3.5 | |
静风压(bar) Static Wind Pressure |
0.13 | |
储Ʊeq(L) Storage Tank Volume |
6 | |
eƺ内径(mm^ Conveying Tube Inner Diameter |
Ф38 | |
teƺ Size of Standard Hose |
Ф38mm×3.5m×1pcs | |
~Τؤo(cm^ Dimension L×W×H |
34×34×59 | |
净 (kg) Net Weight |
12 |
