HY-HYPOID GEAR REDUCER

Precision Hypoid Gear Reducer for Servo Motors
The HY series reduction gear is specially designed for servo motors. Its internal gearbox utilizes a combination of hypoid gears and spiral bevel gears. The most prominent features of this product include ultra-low backlash, high torque capacity, and a high single-stage reduction ratio. The output end can be configured in various ways, including a hollow shaft, single/double-sided keyless shrink disc, and single/double solid output shaft. The Hypoid gear reducer provides users with unique, unparalleled advantages, particularly in high-dynamic servo drive applications.

Product Advantages:
High Performance: Low backlash combined with high torque capacity.
Maintenance-Free: Requires no lubricating oil replacement, ensuring a long service life.
Energy Efficient: The servo reducer boasts an efficiency of up to 90%, significantly reducing energy costs.
Precision & Quiet Operation: Precision-ground spiral bevel gears guarantee low backlash and low-noise performance.
High Reduction Ratios: By combining the spiral bevel gear set with an optimally designed planetary gear system, it can achieve a reduction ratio of up to 1:1500.
High Compatibility: The HY hypoid gear reducer can be seamlessly assembled with all major brands of servo motors.
Applications:
HYPOID GEAR REDUCERS are widely utilized across various servo motion applications, including:
Turnover / Flipping transmission mechanisms
AGV (Automated Guided Vehicle) drive wheels
Rotary tables and turntable applications
Automated packaging machinery
Rotary cutter mechanisms
5-axis machining centers
General automation equipment
Semiconductor manufacturing machinery
Optical equipment
Available Models:
HY55, HY75, HY90, HY115, HY130, HY140, HY160
HY55-25-P2、HY75-15-P2、HY90-25-P2、HY115-50-P2、HY130-15-P1、HY140-25-P1
