Salt Spray Chamber
Model: SSTC-60
Category: Automatic/Industrial Machines & Equipments / Testing Equipment / Inspecting/Measuring Instrument and Parts
Characteristics
Applicable Industry
JOEO Corrosion Test Chamber (SSTC) series of chambers are the industry’s most advanced, flexible and robust test chambers available anywhere in the world.
Salt spray corrosion test chamber can provide the user a wide range of controlled cycles to meet the greatest variety of Industry standard specifications.
Specifications
Salt Fog Test DIN EN ISO 9227 – DIN 50 021
Condensed Water Test DIN EN ISO 6270-2 – DIN 50 017 and EN ISO 6988 – DIN 50 018
Standard Climate DIN 50 014, clause 5 ambient temperature
https://www.chamber-testing.com/products/salt-spraytest-chamber.html
Structure
JOEO's salt spray chamber manufacturers adopts 5mm or 8mm imported gray and white impact resistant P.V.C board, with high temperature resistance up to 85℃ and corrosion resistance.
Support frame: ¢ 10MM fiberglass rod, corrosion resistant. The steel V-frame and the fiber rod angle are placed to ensure the specimen is inclined at 15-30 degrees.
Pressure barrel is welded seamlessly with 2.0mm SUS304 stainless steel plate
- Salt spray corrosion test chamberwith color touch screen LCD controller, which can record the testing curves.
- Program Group Capacity: 140Pattern (Group) 1400Step (above) each program can be set up to Repest 99 segment.
- Each executive mode time can be arbitrarily set 0-999 hours, 59 minutes.
- Each group can be arbitrarily set the cycle of 1-999 .
- Has the power memory function, recovery after power continue to perform the not completed the test.
- interface RS232 connect with computer.
Model Salt Spray
ChamberSSTC-60 SSTC-90 SSTC-120 SSTC-160 SSTC-200 Lab Capacity(L) 110 270 500 800 1500 Internal Dimension
WxHxD (mm)600x400x450 900x500x600 1200x500x800 1600x500x800 2000x500x800 External Dimension
WxHxD (mm)1100x960x760 1400x1200x900 1900x1300x1400 2150x1350x1400 2700x1500x1700 Lab Temperature Saline test (NSS ACSS) 35 ± 1℃; Corrosion Test (CASS) 50 ± 1℃ Pressure Bucket
TemperatureSaline test (NSS ACSS) 47 ± 1℃; Corrosion Test (CASS) 63 ± 1℃ Saline Capacity(L) 15 25 40 40 40 Saline Concentration 5% concentration of NaCI, or every Liter 5% NaCI add 0.26g CuCI2H20 Compressed Air
Pressure(Kgf)1.0 ~ 6.0 Spray Volume 1.0~2.0ml/ 80cm²/h (working at least 16 hours, and take the average value) Spray Form Continuous spraying or programmable spraying Power AC 220V; 1phase 3 lines 50/60Hz Weight (Kg) 65 80 120 160 200
