Specifications



TR21-1,TR22-1,TR21-2,TR22-2 small volume which can input AC110V or AC220V power directly./Drived by PWM rated current and the circuit can suppress vibration which lower down the noise and vibration./Surface Mounting Design for raised stability of circuit./With auto current down circuit and it can depress the motors rise temperature./Self-test function,easy circuit inspection./LED monitered and displayed the driver's condition with full functions. TR22B DC24V power input/The machine case designed by alright structure which can prevent the foreign matter entering/RUN\STOP current adopted digital circuit design which with high precision of current adjustment/Self-test function and easy circuit inspection/Protected by internal PPTC, even if the wrong connection of the polarity(+&-)which can be protected by the function. TD2M DC24 power input/5 options of the stepping angles(200/400/800/1600/3200 pulse/rotation)Low speed with low vibration and running smoothly./High precision of the current adjustment with the RUN/STOP digital circuit./Self-test and TIMING functions for easy circuit inspection/Full protection functions:Over current from input signal, Out of phase, Short circuit, Wrong phase sequency, poor connection TR21PM Drived by Bi-polar and the step angle has full step、half step、1/4step、1/8step switch selectable/Driver including the pulse generated function which can select the pulse generated from internal(INT)or external (EXT)freely/Speed regulated by SPEED knob on the driver panel,easy operation/Operation smoothly with the acceleration/deceleration time setting/Com TR514-1,TR514-2 AC110V or 220V power input with compact size/New driving type-Pentangle which is high efficiency,low noise and vibration, the characteristic of Torque and response improved greatly/SMD design for raised stability of circuit/With auto current down circuit it can depress the Motor's temperature rising/Self-testing/TIMING function and easy circuit inspection/With over voltage protection function,auto current cut off when the input current over the rated value. TR515B,TR530B DC24V power input/The machine case designed by airtight structure which can prevent the foreign matter entering/RUN\STOP current adopted digital circuit design which with high precision of current adjustment/Self-test function and easy circuit inspection/Protected by internal PPTC, even if the wrong connection of the polarity(+&-)which can be protected by the function.
