Model

AEZ-45

AEZ-55

Applicable Material

LDPE

Film Width

60~300mm

200~500mm

Screw Diameter

φ45mm

φ55mm

Screw L/D

30:1

30:1

Screw/Barrel Material

Japan Made SACM-645

JS1 Gearbox

1 SET

Heater Capacity

8 kw

10 kw

Auto Thermo Control

5 ZONE

6 ZONE

Barrel Cooling System

1/4HP ×2

Main Driving Motor

15 HP+Inverter

20 HP+Inverter

Two Layer Air Ring

Aluminum Alloy 1 SET

Extrusion Speed

8~15M/MIN

8~15M/MIN

Air Blower with Inverter

2 HP+Inverter

Joint Unit

1 SET

Rubber Roll Width

400 mm

600 mm

First Pinch Roll

1/2HP GEAR

Second Pinch Roll

1/2HP GEAR

Double Winder

DC 1HP ×2

Machine Dimension

5.6×1.8×4 M

5.8×2×4.8 M

Selective Equipment

Varies Die

Selective Equipment

AEZ25 mm Extruder

※NOTE: All are subject to change without notice. specifications and design characteristics shown in this catalogue
