Cutting Length

300mm~700mm

Cutting Width

90mm~330mm

Cutting Thickness

0.012~0.20mm

Output

250pc/min (Varies depends on shape, thickness size material and etc)

Power Required

6.0KW

Main Motor

AC 2HP x 4P Inverter control

Feeding Motor

AC1HP x 6P Inverter Control

Circule Round Converyor Motor

Servo Motor Drive

Photocell

Germany Sick

Circule Round Converyor Motor & Inverter Speed Control

Heavy Duty Unwind with Air Shaft

EPC + Powder Brake Tension Control

Bottom Gusset Device

Dotted Perforate Device

Waste Film Trimming with Blower

Center/Side Slitter Device

∮12 SAW TYPE HOLE PUNCHING NOTCH&VACUUM SCRAP REMOVAL

Carriage Registration System with Cold Needle

Selective Equipment

CE Self Declaration Modification

∮13 SAW TYPE HOLE PUNCHING(2PC)
