Frequency Inverter - PI5 Series

Enlarge

Frequency Inverter - PI5 Series

Model: PI5 series

Category: Automatic/Industrial Machines & Equipments / Automated Machinery & Equipments / Automatic Control Systems

Online Inquiry

Characteristics

• Energy saving ratio of 25 – 65%. Reduce the number of phase capacitors. Return ofinvestment is very quick
• Reduce motor activating current, particularly in the power supply of generator.
• The temperature of hydraulic oil is reduced significantly (5 - 15°C).
• Reduce the noise. Start and stop smoothly. Eliminate the hydraulic impact.

Specifications

• PI5 Series：Power source 3PH 200~240V
Rated power of the motor(PH/HP/KW)：3PH/7.5/5.5 ~ 3PH/150/110

• PI5 Series：Power source 3PH 380~480V
Rated power of the motor(PH/HP/KW)：3PH/ 7.5/5.5 ~ 3PH/420/315

200V Series	Series No.	2007	2010	2015	2020	2025	2030	2040	2050	2060	2075
	Rated power of the motor(HP/KW)	7.5/5.5	10/7.5	15/11	20/15	25/18.5	30/22	40/30	50/37	60/45	75/55
	Rated output power(KVA)	9.5	13	18	23	28	34	44	55	67	84
	Rated output current(A)	25	33	46	60	74	90	115	145	175	220
	Rated output voltage(V)	3PH 200~240V
	Power source(PH,V,Hz)	3PH 200~240V,50/60Hz
	Tolerance of frequency fluctuation	176~264V,50/60Hz

200V Series	Series No.	2100	2125	2150
	Rated power of the motor(HP/KW)	100/75	125/90	150/110
	Rated output power(KVA)	112	132	154
	Rated output current(A)	295	346	405
	Rated output voltage(V)	3PH 200~240V
	Power source(PH,V,Hz)	3PH 200~240V,50/60Hz
	Tolerance of frequency fluctuation	176~264V,50/60Hz

400V Series	Series No.	4007	4010	4015	4020	4025	4030`	4040	4050	4060	4075
	Rated power of the motor(HP/KW)	7.5/5.5	10/7.5	15/11	20/15	25/18.5	30/22	40/30	50/37	60/45	75/55
	Rated output power(KVA)	11	14	18	23	30	34	46	56	66	84
	Rated output current(A)	14	18	24	30	39	45	61	73	87	110
	Rated output voltage(V)	3PH 380~480V
	Power source(PH,V,Hz)	3PH 380~480V,50/60Hz
	Tolerance of frequency fluctuation	332~528V,50/60Hz

400V Series	Series No.	4100	4125	4150	4175	4200	4250	4300	4420
	Rated power of the motor(HP/KW)	100/75	125/90	150/110	175/132	200/160	250/200	300/220	420/315
	Rated output power(KVA)	114	134	160	193	232	287	316	445
	Rated output current(A)	150	176	210	253	304	377	415	585
	Rated output voltage(V)	3PH 380~480V
	Power source(PH,V,Hz)	3PH 380~480V,50/60Hz
	Tolerance of frequency fluctuation	332~528V,50/60Hz
