Wood Working center
Model: JY-M1325A
Category: Woodworking Machinery Industry / Bonding/ Pressing/ Forming Machinery / Automatic Edge Banding Machine
Characteristics
Applicable materials
Wood, plastic, density board, wave board, PVC, acrylic, crystal, aluminum board, light marble and other nonmetal materials and light metal materials.
Specifications
1300*2500mm Wood Working center JY-M1325A
Model | JY-M1325A | |||||
X,Y Working Area | 1300*2500*200mm | |||||
Table Size | 1440*3040mm | |||||
XYZ traveling positioning Accuracy | +/- 0.005/300mm | |||||
XYZ repositioning positioning | +/-0.005mm | |||||
Table surface | PVC table | |||||
Frame | Welded structure | |||||
Max. Idling Speed | 35m/min | |||||
Spindle Motor Power | 3.5KW China air cooling spindle | |||||
Spindle speed | 0-18000RPM | |||||
Working Mode | Steeper | |||||
Drive | 2811 big YAKO drive | |||||
Operating System | DSP control system | |||||
Interface | USB | |||||
Flash Memory | 128M (U Dish) | |||||
Work-holding | By Suction | |||||
Vacuum system | Yes, with 5.5Kw vacuum pump | |||||
Lathe Structure | Seamless welded steel structure | |||||
X,Y Structure | Rack and pinion transmission,HIWIN guiding rail | |||||
Z Structure | High-precision Rolling Ball screw | |||||
Dust collector | 3.0kw dust collector | |||||
Working Voltage | AC380V/50Hz | |||||
Command | G code,HPGL,U00,mmg,plt | |||||
Diameter of cutter | φ3.175-φ12.7mm | |||||
Package | Wooden case |
Applicable materials | ||||||||
Wood, plastic, density board, wave board, PVC, acrylic, crystal, aluminum board, light marble and other nonmetal materials and light metal materials. |
||||||||
Mahicne Details:
1. Heavy mode lath body, welded by thick hard steel, to make sure the machine’s high stability, precision and efficiency working. Bistratal side panel, to make sure the gantry’s high supporting power.
2. Vacuum table with T-slot, can fix the work piece by suction and clamps. Attractive and durable, easier to operation, also can save your time.
3. Three axes adopt Taiwan HIWIN high precision linear orbit; X and Y axes adopt rack and pinion transmission, fast working, high efficiency and low cost. Z axis adopts ball screw,with high precision
4. Protection device to protect the wire and one emergency switch on each later plate (3 emergency switch totals):
5.Closed tank chain:
6.Adopting China brand 3.5kw air-cooling spindle make the machine have high precision, long life-time and steady working capacity.
Completed Samples as follows:
