Specifications

This machine is directly connected with the tunnel furnace, composed of a machine frame, a transmission roller, a feeding roller, a canvas surface knife, molding system: Automatic Sprinkle sesame mechanism, automatic stripping etc.. Its working principle is: modulated the fabric into the hopper, through feeding feeding roller and die extrusion roller, become the walnut cake blank, and then through the canvas will be driven by the roller blank directly transported into the net with tunnel oven, the machine in the structure is also provided much of the adjusting mechanism: Canvas tensioning offset institutions, regulatory agencies face knife left and right and up and down, canvas stick material cleaning scraping the surface mechanism, the feeding clearance adjustment mechanism. The production skills, crisp, crisp elliptical square cake and crisp biscuit, fruit and other various food oven.

主要参数:

The main parameters:

型 号：TS600/800/1000/1200 模辊直径：φ206mm

Type: TS600/800/1000/1200        die roll diameter: diameter of 206mm

电 源：380V，50Hz 模具转速：3-20r/mim

Power source: 380V, 50Hz             mold speed: 3-20r/mim

功 率：1.5kw 生产能力：200-500kg/h

Power: 1.5kw                            production capacity: 200-500kg/h

外形尺寸：2600×1100×1400mm 机器重量：850 kg

Dimensions: 2600 x 1100 x 1400mm                      machine weight: 850 kg
