Specifications

Shandong Surabaya Xinli machinery factory to meet the development of the times and the needs of the market, continuous innovation in technology, processing technology constantly improving, as cake machine, touch screen cake machine consequential, appear in front of you! Over the years, won the praise of customers in the quality of products and services
   At present, China's food production enterprises in the production of paper cups of cakes mostly by hand squeezing produced, the existence of large labor intensity, low production efficiency, poor sanitary conditions and inaccurate measurement deficiencies. In view of this situation, Surabaya Xinli machinery factory design paste, time-saving reduces effort. The machine adopts intelligent programming, automatic control. In the whole production process, the chain operation of injection plug tray, tray lifting movements such as paste injection, all controlled by program. In order to overcome the ills surrounding the previous manual injection nozzle paste injection caused run material, the lower part of the machine in the pallet chain set up lifting plate, when stopper to paper cups, paste filling, pallet chain rises; when the filling confused after completion, pallet chain fall, which will be more than expected injection nozzle at the bottom of the breaking point. The ending thoroughly more than expected fall in the middle of cup, completely solve the cup surrounding flowing \ and viscosity drops and other undesirable phenomena.

Characteristic.

具有运动稳定、计量准确、注糊量可调(注糊量在10-70克范围内可调)、生产效率高等优点；该机设置了多种档位，能适合3*5、4*6、5*8、6*9等各种规格的烤盘（烤盘尺寸600*400），并能生产双色蛋糕、贝壳蛋糕、夹心蛋糕、欧式纸杯蛋糕、欧式麦宝蛋糕、魔堡蛋糕、娃娃脸蛋糕、冰激凌蛋糕及各种不同形状的蛋糕（根据所配模具的不同而不同），一机多用；打开料斗快速压紧杆，可取下料斗及注糊装置，具有清洗方便、操作简单等优点。

With stable motion, accurate measurement, paste filling volume can be adjusted (adjustable paste injection quantity in 10-70 g range), production efficiency higher merit; the machine is provided with a plurality of gear, suitable for 3*5, 4*6, 5*8, 6*9 and various specifications of the tray (tray size 600*400), and can produce double color eggs cake, cake, cake, European Cup Cake, European Mai Bao cake, cake, a clear allusion to baby face cake, ice cream cake and all kinds of different shape of the cake (according to the matched mould is different), multi use of one machine; open the hopper fast pressing rod, a removable hopper and paste injection device, has the advantages of convenient cleaning, simple operation etc..

The main parameters:

型 号：SZH 600×2 单个挤出量:10-65g / 个

Type: SZH 600 * 2 single extrusion capacity: 10-65g / A

电 源：220V, 50Hz 托盘尺寸：600×400mm

Power source: 220V, 50Hz size: 600 x 400mm

配用气源：0.6-0.8 M Pa , 0.2㎡/min 生产能力：800-1000 kg /8h

Source: 0.6-0.8 M Pa, with 0.2 square meters of production capacity: /min 800-1000 kg /8h

外形尺寸：3000×1100×1300mm 机器重量：720kg

Dimensions: 3000 x 1100 x 1300mm machine weight: 720kg
