Specifications

Introduction:

Arduino basic learning kit is designed for Arduino fans and users by Yie shuen tech. Even if you do not learn any related skills of electronic circuit, you can easily follow the manual to complete every designed experiment step by step. In the whole operation process, you only have to connect/plug & pull components through jumpers on breadboard, no soldering needed. Except for the learning introduction of Arduino, there are also 13 sections of experiment courses considered about beginner’s learning interest, from easy to hard, step by step and well organized. Every experiment includes principle description, materials, connection methods, code, results and etc.

Contents:

 Arduino introduction………………………………………………………………………… 4

 Breadboard Introduction........................................................ 17

Basic experiments

1、Hellow Test …………………………………………………… 19

2、LED Test… ……………………………………………………… 22

3、Traffic sign Test………………………………………………… 28

4、LED control Test   ……………………………………………… 32

5、Analog value reading test………………………………………… 37

6、Light control buzzer test…………………………………………… 42

7、Seven-segment display test………………………………………… 47

8、Responder test……………………………………………………… 55

9、LM35Temperature test   ……………………………………………… 61

10、Relays application test………………………………………………. 65

11、74HC595application test……………………………………………..73

12、PWM control DC motor rotational speed test……………77

13、Pyroelectric infrared sensor test………………………………………83
