Specifications

Specifications：( CE & FCC )

Control circuit:           Microcomputer control
Control mode:           Teach or Normal

Dispensing pressure:   0.7MPa (max)

Dispensing set time:   0.01 sec. (step) ~ 99.99 sec.(max)

Vacuum pressure:      -20kPa (max)

Shot mode:                Timer, Manual or Reshot (Option)

Monitor:                     Watchdog timer

I/O signal:                   In. =Contact or Non contact

                                    Out. =Contact

Supply air pressure:   0.8MPa or less

Power source:            100~240Vac 50/60 Hz

Dimension:                 W230 x D200 x H110mm
