Specifications



Model: SU-1800 (2-CAVITY )
Material :PET
Volume :0.05-2.5(2-cavity) 3-6(1-cavity)L
Max. length of bottle mm 350
Bottle diameter mm 35-120(2-cavity)
Max. mould plate dimension(L*H) mm 350×450
Max. mould thickness mm 180-240
Clamping force KN 200
Mould opening stroke(Adjustable) mm 180-260
High pressure compressor M3/Mpa KW ≥0.7/3.0×2set 15
Low pressure compressor M3/Mpa KW ≥1.6/1.0×2set 7.5
Air cooling dryer M3/Mpa KW ≥1.0/3.0×1set 0.375
Precision air filters M3/Mpa ≥1.0/3.0×3pcs
High pressure air receiving tank(D*H) M3/Mpa M ≥0.6/3.0×1set 0.375
0.7×2.55
Dimension(L×W×H) M 2.0×1.9×2.2
Power KW 15
Voltage/Frequency V/HZ 220-380/50-60
Main body dimension(L×W×H) M 2.2×1.7×2.1
Main body weight T 2.6
Conveyor dimension( l×w×h) M 2.0×1.05×2.18
Conveyor weight T 0.3
