Hand Held Edge Bander
Model: Portable edgebander 07 08 09 collection
Category: Woodworking Machinery Industry / Multi-Purpose Woodworking / 5 In 1 Woodworking Machine
Characteristics
- Special design for glue systems, structural stability ,
long service life and will not leak glue , and coating uniformity;
- Multi-function, to adapt to a variety of material, size, to provide straight
edge, inside the arc, outside the arc, curve and circle are suitable.
- Suitable for all kinds of Edge band, such as Melamine paper band, wooden
band, and plastic (PVC or ABS) self-adhesive edge band.
- Safety use , All the electronic components passed CE and UL / CSA
certification standards. Temperature control work to reach pre-set and
then can be activated.
Specifications
Portable Edge Banding machine
Technical Parameters (07-08) / (09)
The thickness of Edge band o.3mm ~ 3.00mm / o.3mm ~ 3.00mm
The minimum / maximum width 10mm ~ 45mm / 10mm ~ 60mm
Low temperature hot-melt adhesive 120 C ~ 170 C / 120 C ~ 170 C
The warm – up time 10 minutes~15 minutes / 5 minutes~ 10 minutes
Speed for edge banding 4m / 4m
Speed control can adjust 2m ~ 6m (speed stepless)
Total power usage 765W (with 15W motor) / 525W (with 25W motor) / 765W (with 15W motor)
The size for machine 400 X 280 X 380mm / 330 X 300 X350mm
The net weight for machine 11KGS / 8KGS
Input power 220V / 110V single-phase
