Hyperbolic helical gear reducer
Model: TKM28B . 28C Coordinated Gear Reducer
Category: Machinery Parts and Components / Machinery Parts and Components / Gear Motors
Characteristics
TKM28B.TKM28C
1. Gear material - Made of imported steel such as special alloy steel.
2. Gear processing - Special tool full gear skiving processing with stable quality, low noise and high transmission efficiency.
3. Gear oil - high temperature resistant lubricant, high temperature resistant, good lubrication effect, permanent oil change maintenance free.
4. Gearbox - The gearbox is die-cast and reinforced with good texture. Beautiful appearance.
5. Appearance - Surface treated with high temperature powder coating, acid and alkali resistant.
6: Coupling - The connection between the motor and the reducer (expansion type structure connection transmission) has a longer service life.
7. Gear - carburizing and quenching, surface hardness 56-62HRC, penetration depth after fine grinding maintained at 0.3~0.5mm.
8. Output shaft - hollow Φ25/K8, can completely replace RV50 hollow turbine specifications.
For IEC standard motor 71 frame/B14 200~400W motor
Applicable occasions - PCB dry and wet processes, woodworking machinery, conveyor belts
