Specifications



Max. Swing Diameter Ø480mm
Max. Cutting Diameter Ø300mm
Work Length 520mm
Spindle Nose ASAA2-6
Spindle Bore Diameter Ø62mm
Bar Capacity Ø51mm
Hydraulic Chuck Ø210mm
Spindle Speed 4000rpm
X-Axis Travel 176mm
Z-Axis Travel 450mm
X-Axis Rapid Feed Rate 20m/min
Z-Axis Rapid Feed Rate 20m/min
X-& Z-Axis Feed Rate 0.001-500mm/rev.
Tool Rest Number (Random) Std:LS-200SVX8T Servo Turret
Tool Holder 25x25mm
Spindle (Continuous turning) β8/8000i AC7.5kw(2.4HP)
Spindle (30 min. constant speed) AC11kw(15HP)
AC Servo Motor (X-Axis) β12/3000i AC1.8kw(2.4HP)
AC Servo Motor (Z-Axis) β12/3000i AC1.8kw(2.4HP)
Hydraulic Pump 2HP
Cutting Pump 1/4HP
Quill Diameter Ø80mm
Quill Travel 100mm
Center Taper MT No.5
Tailstock Travel 425mm
Hydraulic Tank Capacity 40Litre
Coolant Tank Capacity 80Litre
Dimensions (LxW) 3400x1800mm(including iron filings conveyer)
Overall Height 1800mm
Net Weight 3700kg
Dimensions (LxW) 3600x2000mm(including iron filings conveyer)
Overall Height 2100mm
Gross Weight 4600kg
