oil skimmer oil pump
Model: ECO MS 75 ECO SC04
Category: Automatic/Industrial Machines & Equipments / Industrial Machines / Pollution Abatement Equipment
Characteristics
The ECO Multi-Function Skimmer is accepted around the globe as the most versatile and reliable skimmer in the world. It is a flexible high capacity free-floating skimmer, which is designed with interchangeable brush wheel, disc bank, and drum modules that can change in less than 3 minutes with no tools. The Multi- Function Skimmer can be equipped with three of each type of skimmer units or with a combination of all three to allow for skimming a complete range of oils and viscosities from light diesels up to heavy crudes.
Standard units come complete with skimmer head, pump unit, hydraulic and transfer hoses, and hydraulic power unit.
Specifications
ECO- BR 75
刷式式汲油頭組
Body construction : Marine Grade Aluminum
L*W*H : approx. 1500mm *1500mm *800mm
Draft : 600mm
Number of beam : 4
Weight : around 160 kg
Outlet Gauge : 3” cam‐lock
Discharge hose : 2*15M with cam‐lock, dia3”
2. ECO SC03 (onboard)
油壓輸油泵浦
UP TO 80 M3/HR /15KG
Viscosities to 25,000 CST
Body construction : Marine Grade Aluminum
Portable pump designed for pumping jobs such as Spaces Oil
Lubricated Seals (Can Run Dry) Will Pass 1.5 in Semi‐Solids
Variable Speed Hydraulic Drive Wide Range of Performance
Safe Hydraulic Drive can be used where
3. POWERPACK
ECO PP20 DIESEL
Engine :upto 20HP AIR COOL
20HP HYDRAULIC POWER SYSTEM /160KG l l
引擎油壓動力機組
及管線配件
or same level
Efficient air Cooled Engine. UP TO 3000 PSI
Hydraulic hose : 15M with quick connect
(2 sets 4 line for pump and skimmer)
