Specifications

*Isolation : magnetic coupler
*Baud Rate : 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200, 921600
*Data Bits : 5, 6, 7, 8
*Stop Bits : 1, 1.5
*Parity : None, Even, Odd
Digital Input
*Input Points : max 16 (Configurable)
*Logic High Level : 3.15V (min)
*Logic Low Level : 1.35V (max)
*Over-Voltage Protection : 60Vdc (max)
*Over-Current Protection : 50mA (max)
Digital Output
*Transistor Output : max 8 (Configurable)
*Transistor Capacity : 500mA (peak), 45Vdc (max)
*Standalone function : 32 steps control in struction
Ethernet
*10/100M auto switch x 2 port
*WDT : 1~1000sec based on 0.1 sec time base for communication discontinuity detect
*Response time 2ms
General
*Power Requirement : 12Vdc ~ 24Vdc
*Operation Temperature : 0°C ~ +70°C
*Storage Temperature : -20°C ~ +80°C
*Operation Humidity : 5% ~ 95% RH, non-condensing
*Dimensions : 107.6(D) * 135.8(W) * 34(H) mm, 4.3(D) * 5.4(W) * 1.4(H) in
