Automatic Ultrasonic Seal Pyramid Rose Tea Bag Packing Machine with Thread and Tag
Model: C20DX
Category: Packaging, Printing, Food & Pharmacy Machinery / Packaging Machinery / Blister & Strip Packaging Machines
Characteristics
1) Automatic multi-function packaging forming machine;
2) Suitable for all kinds of drinking tea leaves, herbs and flowers;
3) Ultrasonic sealing method, Convertible pyramid and flat bag type;
4) Nylon(PLA/non-woven) bag materials; with thread and tag;
5) High quality with international brand-name parts;
6) All-round process: filing, weighing, bag forming, sealing, cutting and counting etc.
7) Quality Approval: CE, ISO9001:2008
8) Manufacturing experience: 12 years
Specifications
C20DX Automatic Pyramid Tea Bag Packaging Machine with 4 Electric Scales
Application:
It is suitable for packing products such as loose leaf tea, herbal tea, health care tea, rose tea, ginseng and other Chinese kinds of local tea, etc.
Technical data:
Machine type: |
Tea Bag Packing Machine Series |
Machine model: |
C20DX |
Machine name: |
Automatic Pyramid Tea Bag Packing Machine with 4 Electric Scales |
Packing material: |
Nylon material imported from Japan, non-woven fabric, 100% biodegradable transparent materials, PET, PLA, etc |
Measuring: |
Electric scale filler |
Filling range: |
1-10g/bag, accuracy: ≤ ±0.1g/bag |
Packing speed: |
30~50 bags/min |
Packing roll width: |
140, 160, 180(mm) |
Sealing length: |
50, 60, 70, 80(mm) |
Sealing method : |
Sealing and cutting by ultrasonic |
Quantity of sealing device : |
2 sets |
Air supply: |
≥0.6MPa(can be equipped with air compressor) |
Motor power: |
220V, 50HZ, 1.2KW |
Dimension: |
1800*900*2300mm(L*W*H) |
Machine weight: |
400KGS |
//Features: //
1. The feasible package materials of the triangle bag machine is nylon, PLA, non-woven fabric materials imported from Japan, which is non-toxic, non-bacteria, heat-resistant, high-quality and food-grade, conforming to our national safety inspection standard.
2. The machine can uses a unique sealing method - ultrasonic. It can seal tightly, safely, and reduce the width of the extra edge, avoiding any waste of packing materials.
3. The machine can switch the bag shape between pyramid(triangle) and flat(rectangle), and also the sealing method can be switched into back sealing.
4. The machine can be linked with the outer pouch packing machine.
5. Each electric scale of this machine is independent, each one can be operated alone.
