About Speed Control Motor



Model: 5IK60RGN-CF

Category: Packaging, Printing, Food & Pharmacy Machinery / Printing Presses / Pad Printing Machines



Online Inquiry





Characteristics



Able to change speed when running
◎ Output From 6W to 150w
◎ Range of speed adjustment is (50Hz)90~1400, (60Hz)90 ∼1600 　　　
◎ Wiring has separate or compose types to choose
◎ Gentry start or stop function is attach with separate type　　


Standard Speed Control Motor type
　Item Specifications
Insulation resistance Use a DC500V high resistance gauge to measure the coil of motor and it's a outer shell when motor running in normal temperature and normal humidity, its value should be above 100MΩ .
Insulation pressure endurance Apply 60Hz, 1.5kV at the coil of motor and it's a outer shell for one minute without and extraordinary phenomenon when motor running in normal temperature and normal humidity.
Temperature arise Install two reduction gears or radiation plate of the same class at the motor. After rated running, test the coil by resistance method. Its value should be less than 80°C.
Insulation Class Class B (130°C)
Overheat protection Over heat shut down system.
Environment temperature -10°C∼+50°C
Humid around the environment Below 85% (No frosting happen)
▲ Over heat shut down system is not a standard device, please notice before order.
