HYDRODYNAMIC AUTOMATIC BAR FEEDER
Model: RAY-323
Category: Machine Tools / Others / Other Machinery
Characteristics
Bar Diameter Φ 3.0mm∼Φ 23mm
. Hydraulic type, high loading and ensures silent turning.
. Various parameter settings, alarm detection and function display.
. Employs Mitsubishi AC servomotor to transmit.
. Adopts PLC control circuit featuring excellent stability and easy
operation.
. High-density steel structure ensuring rigidity and durability.
. Mechanical synchronized device fits sliding headstock CNC lathe and
assures fast and stable feeding.
. Quick-change guide channel easy and convenient to change.
Specifications
| TYPE | RAY-12 | RAY-16 | RAY-20 | RAY-23 | RAY-26 | |
| Bar Diameter | .jpg) |
ø3~12mm 1/8"-1/2" |
ø3~16mm 1/8"-5/8" |
ø3~20mm 1/8"-25/32" |
ø3~23mm 1/8"-7/8" |
ø5~26mm 3/16"-1" |
.jpg) |
4~11mm 3/16"-7/16" |
4~14mm 3/16"-9/16" |
4~17mm 3/16"-11/16" |
4~19mm 3/4"-13/16" |
4~21mm 3/16"-13/16" |
|
| Channel Size | 14 | 18 | 22 | 24 | 28 | |
| Bar Loading Capacity | 200mm ø10mm x 20(bar) | |||||
| Air Supply | 5-7kg/cm2 | |||||
| Power Supply | 3Phase 200~240VAC 5A 50/60HZ | |||||
