Specifications

Specification:
1. Screen fixed by pneumatic method, easy to operate
2. Evenness and ligh of aluminum honeycomb working table
3. Quality peel off device makes squeegee and height of screen lifting simultaneously
4. No trembling during up and down movement of the side frame by selecting the inverter control
5. Mitsubishi motor and all key parts from Japan, Germany, Italy, Korea, Taiwan to make sure quality
6. Combined integrated cylinder scraping blade improve stability
7. Emergency stop ensures operator's safety and reduces defective rate

Optional:
1.) Swing type scraper and ink blade
2.) Destop blowing setting
3.) Touch screen control panel
4.) Automatic monitor control printing lift
5.) Light weight worktable

Parameter:
Model                                        PSA-6050                    PSA-8060                       PSA-1280
Max printing size                600 X 500mm             800 X 600mm               1200 X 800mm
Printing table size              750 X 710mm            900 X 800mm               1320 X 1000mm
Printing speed                  Max.1100 cycle/h       Max.1000 cycle/h            Max.900 cycle/h
Maximum frame size (OD) 900 X 900mm       1100 X 1000mm            1500 X 1300mm
Min frame size (OD)            500 X 500mm        600 X 600mm                800 X 800mm
Printing pressure                                                       0 ~ 95kgf
Scraping speed                                                100 ~ 800mm/sec
Scraping angle                                                          60° ~ 90°
Scraping Bias                                                                  6°
Screen vibration                                                     0 - 25mm
Printing work height                                          900(+/-50)mm
Material thickness                                                 0 ~ 50mm
Frame fixing                                                       Cylinder Clamp
Air pressure                                                             6kgf/cm2
Weight                           Approx. 570kg              Approx. 610kg                   Approx. 710kg
Power                                                           220V(380) X 3ph X 2kW
Dimension (W X D X H)    800 X 1650 X 1380mm   990 X 1700 X 1380mm  1350 X 1900 X 1380mm


★ Special specification can be made for customized requirement.
