Specifications

Specification：
This device is easy to operate by a touch screen panel to make operation simple.
Using frequency inverter to control water and adjust pressure which makes more stable and reliable performance.
Using Mitsubishi PLC for internal data processing, can be set and stored 20 groups parameters, when you need to use one of them, just call up the parameter group number, then the corresponding parameter would come up which make operation much more convenient to use.
The main parts use Mitsubishi, Omron, Panasonic, SMC, Fuji and other famous international brands to make the device more stable performance. The machine body made of high quality 304 stainless steel, corrosion resistance, and make the body more firmly and beautiful.

Feature：
(1) Double-sided synchronous spraying.
(2) Internal stainless steel, non-corrosive, excellent durability.
(3) To adjust the pressure according to different network version of the species.
(4) Use filtration cycle to save water.
(5) The pressure of the standard operating instructions is simple.
(6) Using mixed gas knife to shorten the drying time.

Parameter:
Model                                                               WAU-1000
Maximum frame size                                     1000*1000mm

Minimum frame size                                      400*400mm

Power                                                               380V

Dimension                                                      2400*1250*2190mm

Function                                                          Automatic screen washing and developing

Nozzle                                                             OKO

Nozzle moving                                              Cross and up-down

Material                                                          304 stainless steel

Internal piping material                              corrosion resistance and anti-rust

Air flow                                                          10m3/h

PLC                                                               Panasonic

Water pump                                                Lift 65m   Pressure:0-5 Kg/cm2 Motor:3kw

Florescent lamp                                       6-8pieces

★ Can be make for customized frame size and model
