Specifications

Feature：
(1) Back-front nozzle design, double-sided synchronous cleaning screen.
(2) Main construction stainless steel, non-corrosive.
(3) Screen size in the maximum range can be freely adjustable, we can make based on your largest screen size.
(4) Cleaning left-right stroke can be freely adjusted.
(5) HMI operation system to facilitate multiple settings.
(6) Freely set pressure, cleaning times, speed and other relevant parameters.
(7) Water filtration system is optional.

Parameter:
Model                                                            WAU-1225
Maximum frame size                                 1200*2450mm

Minimum frame size                                  400*400mm

Power                                                           380V

Dimension                                                  2042*900*3550mm

Function                                                      Screen developing, decreasing and decoating

Nozzle                                                         Japan import stainless steel nozzle,

Nozzle moving                                           Cross and up-down

Material                                                       304 stainless steel + framework spray paint

Internal piping material                            corrosion resistance and anti-rust

Air flow                                                         200m3/h

PLC                                                              Delta

Water pump                                                Lift 65m   Pressure:0-5 Kg/cm2 Motor:5kw

Florescent lamp                                        10pieces

★ Can be make for customized frame size and model
