Kiva Type Big ELFIN Automated Guided Vehicle Warehouse Logistics AGV Robot
Model: OK-AGV-ELFIN
Category: Automatic/Industrial Machines & Equipments / Automated Machinery & Equipments / Automatic Material Handling Equipment
Characteristics
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
OKAGV
Model Number:
OK-CCXL-BHX-AGV
After-sales Service Provided:
Engineers available to service machinery overseas
Name:
automated guided vehicle wheels
Other name:
Modern Design automated guided vehicle wheels
Navigation:
2D barcode
Load capacity:
1000kg
Moving direction:
Pivot, forward, backward
Type:
Kiva warehouse robot
Accuracy:
5mm
Charging:
Automatical
Protection:
safety sensor
Brand:
OKAGV
Specifications
Description of Big ELFIN Automated Guided Vehicle Warehouse Logistics AGV Robot:
It works navigated by Inertia 2D bar code,small, agility, high accuracy and fast.The functions includes automatically avoiding obstacles,flexible route design,long time load holding.Elfin can move the shelf rack of the cargo from big warehouse storage district to certain required area,which highly increase the efficiency of transportation logistics.Overall 50% efficiency raises after using Elfin robots.
AGV Type | Elfin warehouse transfer robot |
Size | L900*W700*H380(mm)customized |
Control | Intelligent motion control system |
Navigation | Inertial navigation,2D barcode navigation |
Moving | Forward,rotate |
Communication | Wireless communication(optional) |
Driving mode | Differential drive |
Driving power | DC48V |
Lifting mode | Automatic lift |
Loading capacity | 1000KG(customized) |
Moving speed | 0-80m/min(customized) |
Guidance accuracy | +/-30mm |
Working time | 24 hs |
Gradeability | 3-5 degrees |
Stop accuracy | +/-10mm |
Charging mode Safety sensor range | manually |
Battery | Li battery |
Safety sensor range | +/-5m,adjustable,emergency stop distance<20mm |
Working environment | Indoor temp:0-40,Relative humidity:40%-80% |
Safety protection | Laser obstacle sensor |
Designed lifespan | >10 years |
Pictures of automated guided vehicle wheels:
