AC FAN



Model: 8038A2-HSAPL

Category: Packaging, Printing, Food & Pharmacy Machinery / Packaging Machinery / Packaging Material / Machine Wholesale



Online Inquiry





Characteristics



Size: 80*80*38mm. (3.15*3.15*2.815 inch.)
Motor: Shaded pole, impendance protected.
Frame(Houseing): Aluminum die-cast. AP: Painted black.
Impeller: PBT + 30% fiber glass. Black color, UL94V-0.
Lead wire: 1007#22AWG. UL/CSA.
Insulation resistance: Min.100M Ohm at 500 VDC between terminal and the frame.
Dielectric Strength: 1 sec at 1500 VAC.50/60 HZ.
Bearing type: B: 2 ball bearing. S: 1 Sleeve bearing
Operating Temp: Ball bearing: within-20~80 degree C
Sleeve bearing: within -10~56 degree C
Life expectancy: Ball bearing: 50,000 hours at 60 degree C.
Sleeve bearing: 20,000 hours at 45 degree C.
Above measurements Tem. at: Within 20~30 degree C.
Above measurements humidity at: 65%+-15%.
Safety Approvals: CE
Net weight : 290 grams (0.82 pounds)
