2-port RS-232/422/485 serial device server
Model: E-P732-X
Category: Automatic/Industrial Machines & Equipments / Auto-Control Panel Design/Installation / CNC Controllers for Machine Tools and Industrial Machinery
Characteristics
•Virtual COM Driver for Windows 7 / Vista / XP / 2003 / 2000
•Standard TCP/IP interface and versatile operation modes
•Easy-to-use Windows utility for configuring multiple device servers
•Built-in 15 KV ESD protection for all serial signals
•Configure by Telnet or web browser
•API for COM port Control
Specifications
Hardware
CPU¡GARM-7 32-bit CPU, 25 MHz
RAM¡G2M bytes SDRAM
ROM¡G128K bytes Flash ROM
Ethernet
Port Type¡GRJ-45 Connector
Speed¡G10 / 100 Mbps ( Auto Detection )
Protocols¡GARP, IP, ICMP, UDP, TCP, HTTP, DHCP
Mode¡GTCP Server / TCP Client / UDP / Virtual COM / Pairing
Setup¡GHTTP Browser Setup ( IE )
Security¡GSetup Password
Protection¡GBuilt-in 1.5KV Magnetic Isolation
Serial Port
Port¡GRS-232 * 1 Port, RS-422 / 485 * 1 Port
Port Type¡GRS-232 : DB9 male
Port Type¡GRS-422 / 485 : Terminal Block
Speed¡G300 bps ~ 230.4K bps
Parity¡GNone, Odd, Even, Mark, Space
Data Bits¡G5, 6, 7, 8
Stop Bits¡G1, 2
RS-232¡GRx, Tx, GND, RTS, CTS, DTR, DSR, DCD
RS-422¡GRx+, Rx-, Tx+, Tx- ( Surge Protection )
RS-485¡GData+, Data- ( Surge Protection )
Built-in RS-422 / RS-485 Terminal Resistor
15KV ESD for all signals
