Specifications



CPU : 32-bits ARM-7 Winbonds CPU , 80 MHz
RAM : 16 M Bytes SDRAM
ROM : 4 M Bytes Flash ROM ( 2M for User Programming )
OS : uC-Linux OS , Provide API,CGI for Customer Programming

Ethernet
Port Type : RJ-45 Connector
Speed : 10 /100 M bps ( Auto Detecting )
Protocol : ARP , IP , ICMP , UDP , TCP , HTTP , DHCP
Protocol ：PPPoE , DDNS , NTP , FTP , Telnet
Mode : TCP Server / TCP Client / UDP
Setup : HTTP Browser Setup (IE & Netscape) , Console
Security : Setup Password
Protection : Built-in 1.5KV Magnetic Isolation

Serial Port
Port : RS-232 / 422 / 485 * 1 Port ( 3000 V DC Photocouple isolation Protect )
Speed：300 bps ~ 230.4 K bps
Parity：None , Odd , Even , Mark , Space
Data Bit：5 , 6 , 7 , 8
Stop Bit : 1 , 2
RS-232 Pins : Rx , Tx , GND , RTS , CTS , DTR , DSR , DCD
RS-422 : Rx+ , Rx- , Tx+ , Tx- ( Surge Protect ) ( Over current protect )
RS-485 : Data+ , Data- ( Surge Protect ) ( Over current protect )

15KV ESD for all signals

Digital Input / Output
Digital Input * 6 Pins ( Active High / Active Low Selectable )
Dry contact : Logic level 0 : close to GND , Logic level 1 : open
Wet contact : Logic level 0 : 0~3 V , Logic level 1 : 10 ~ 30 V
Digital Output * 3 Pins ( Active High / Active Low Selectable )
120VAC @ 10A 240VAC @ 7A 24VDC @ 10A
I2C Interface * 1 port : for Digiatl I/O extend
USB ( Host * 1 port ) : for Memory Storage
Watch Dog Function
