15 opening hot press machine,lamination press machine

Model: BY214*8/6-15

Category: Woodworking Machinery Industry / Bonding/ Pressing/ Forming Machinery / Hydralic Forming Machine

Online Inquiry

Characteristics

The hot hydraulic press is widely used in plywood industry, JOINTING DECORATION VENEER AND PAPERS,lamination press panel boards, floor plants.
Heating method could be choose, steam or heat conducting oil heating method.
Pressure, plate size, opening, all could be set according to user's requirement.

Model BY214*8/4-15 BY214*8/6-15
Nominal pressure(kn) 4000 6000
Hot-press plate sizes (mm) 2700*1370*42 2700*1370*42
Finished piece dimensions in feet 4*8 4*8
Opening(mm) 70 70
Floor number 15 15
Diameter of plunger case (mm) 2-320 ; 1-200 2-320 ; 1-200
Working stroke (mm) 1050 1050
Working pressure (mpa) 25 25
Motor pressure (kw) 26 26
Closing speed (m/min) 4 4
Overall dimension(mm) 5000*1446*5395 5000*1446*5395
Weight(kg) 34000 35000
